Technical Specifications
Performance
| Total Cores | 2 |
|---|---|
| L3 Cache | 4MB (shared) |
| L2 Cache | 1256K (per core) |
| L1 Cache | 96K (per core) |
| TGP | 15 W |
Graphics
| Integrated GPU | UHD Graphics Xe G4 48 EUs |
|---|---|
| Execution Units | 48 |
Technical
| Vendor | Intel |
|---|---|
| Released | October 17, 2020 |
Other Specifications
| File compression | 255.8 MB/sec |
|---|---|
| Clang compilation | 16.5 Klines/sec |
| HTML 5 Browser | 63.5 pages/sec |
| PDF Renderer | 83.7 Mpixels/sec |
| Text processing | 117.8 pages/sec |
| Background blur | 14.7 images/sec |
| Photo processing | 38.5 images/sec |
| Ray tracing | 2.96 Mpixels/sec |
| Integer math | 14.8 GOps/sec |
| Floating point math | 9.2 GOps/sec |
| Find prime numbers | 19M Primes/sec |
| Random string sorting | 6.8M Strings/sec |
| Data encryption | 3 GBytes/sec |
| Data compression | 55.9 MBytes/sec |
| Physics | 370 Frames/sec |
| Extended instructions | 4.2B Matrices/sec |
| Geekbench 6 Multi / Watt | 190.9 PPW |
| Passmark CPU Mark / Watt | 345.1 PPW |
| Blender / Watt | 1.35 PPW |
| Type | Laptop |
| Instruction Set | x86-64 |
| Codename | Tiger Lake |
| Model number | 7505 |
| P-Cores | 2 |
| P-Threads | 4 |
| Base Frequency (P) | 2.0 GHz |
| Turbo Boost Frequency (P) | 3.5 GHz |
| Total Threads | 4 |
| Bus Frequency | 100 MHz |
| Multiplier | 20x |
| Bus Bandwidth | 4 GT/s |
| Unlocked Multiplier | No |
| Fabrication Process | 10 nm |
| TDP (PL1) | 15 W |
| Socket | BGA-1449 |
| Peak Temperature | 100°C |
| Integrated Graphics | Intel UHD Graphics Xe G4 48 EUs |
| GPU Base Clock | 400 MHz |
| GPU Boost Clock | 1250 MHz |
| Shading Units | 384 |
| TMUs | 24 |
| ROPs | 12 |
| Memory Types |
|
| Max. Memory Size | 64 GB |
| Memory Channels | 2 |
| ECC Support | No |
| Official Site | Intel Pentium Gold 7505 official page |
| PCI Express Version | 3.0 |
